D-8B Single-Hood Dishwasher With Electric Heat And Booster Integration

Description

Features

• 55 racks per hour
• Water consumption per rack 1.3 (gal) 4.9 (L)
• Inlet water temperature 140°F, 60°C
• Operating cycle time is 60 seconds
• Wash tank heater is 3000 Watt
• Wash pump power is 1.5HP
• Electric heat with 12,000 Watt booster
• Automatic wash fill tank
• Removable drain filter and scrap screens
• Standard two (2) dish racks and two (2) combination racks for cups, bowls, glasses and silverware
• Easily converted from straight-through to space-saving corner installation
• Optional built-in detergent & rinse dispensers

Electrical

• D-8B, 208-240V/50-60Hz/1Ph Total Amps 82.9A – 72.1A, 16,200 Watts
• D-8B, 208-240V/50-60Hz/3Ph Total Amps 54.2A – 47.5A, 16,200 Watts
• D-8B, 480V/60Hz/3Ph, Total Amps 25A, 16,200 Watts

Dimensions

• 30.5″ W x 25.75″ D x 58″ H (774mm x 654mm x 1473mm)
• Unit weight: 405lbs (183.7 kg)

Shipping Specifications

• 42″ W x 40″ D x 72″ H (1066mm x 1016mm x 1828mm)
• Shipping weight: 450lbs (204.1 kg)

*Item not approved for sale in California
